Pulsar Axion KEY XM22 Thermal Imaging Monocular Detajli

Pulsar Axion Key XM22 enables an easy observation due to its compact design, low weight, and ergonomic build.
Enormous internal memory storage – 16 GB
Axion Key XM22 has a brand new APS3 battery which can quickly be changed without any inconveniences
The Key XM22 unit has an LCOS display which enables immaculate visual interpretation of the observing object

Introduction
There are two basic differentiations of the Axion units – models which have an acronym „Key“ in their name and models without one. Models with a „Key“ acronym don’t have a Wi-Fi and video recording software integrated into its construction while the units without the „Key“ have this software available for use.
About the Axion series
Pulsar Axions are remarkably lightweight and compact pocket-sized thermal monocular units which were released at the start of 2019 as a substitute for the Quantum Lite models which were discontinued in 2019.

Every Axion model out there has three calibration modes (automatic, semi-automatic, manual) like the Helion units.

Axion XM has an enviable 16 GB of internal memory for a purpose of storing images and videos. When it comes to a display, Axions are available with an LCOS – 960×720 and a brand new HD AMOLED 1024×768 microdisplay. LCOS display is integrated into the Key XM models, while AMOLED is built in the XM units which lack the Key acronym.

The HD AMOLED display is designed to face freezing temperatures all the way up to -25°C while LCOS display can stand up to -10°C.

With Axion, you are able to display a thermal image in 8 different colors. The White Hot and Black Hot are predominantly used for detection activities,
About the model (Axion Key XM22)
The Key XM22 model has a picture in picture 2-8x digital zoom and 2x optical magnification. With this model, a maximum observation distance for an animal, such as a deer is 950 m. The field of view is 17.5 m/100 m which means that this model is more appropriate to use on shorter distances. Angular field of view of the Key XM22 unit is 10°. If your sole purpose is to observe an object without a need of taking pictures or videos then this unit (Key XM22) is the one you are looking for.

Main features:

16 GB of internal storage
Quick-change APS3 battery
Compact
Lightweight
Ergonomic rangefinder-like
HD AMOLED microdisplay (XM30, XM38)
LCOS display (Key XM22, Key XM30)
Full waterproof – IPX7
8 thermal color patterns (White Hot, Black Hot, Red Hot, Red Monochrome, Rainbow, Ultramarine, Violet and Sepia)
Calibration modes (automatic, semi-automatic, manual)
12 μm pixel pitch
50 HZ frame rate
Built-in video & sound recorder (XM30, XM38)
Made from rugged magnesium
Stream Vision compatibility (XM30, XM38)

Warranty
The manufacturer offers 3 years of warranty for this product.
Pulsar Axion KEY XM22 Thermal Imaging Monocular specifikacije

Proizvajalec
Pulsar

Termalni enogled
Pulsar Axion

Poreklo
Litva

V proizvodnji od
2019

Garancija
3 leta

SKU
77424

Variabilna povečava
Ne

Povečava.
2x

Najmanjša povečava.
2x

Največja povečava
8x

Nastavitev dioptrije
-4 / +5 Dpt

Premer leče
22mm

Vidno polje
17.5m/1000m

Zorni kot (v stop.)
10°

Min. vidno polje
0m/1000m

Max. vidno polje
0m/1000m

Odaljenost očesa od leče
0mm

Najmanjša razdalja ostrenja
3m

Zaslonka objektiva
F 1.2

Doseg detekcije
950m

Toplotni senzor
Ne

Resolucija toplotnega senzorja
320×240

Št. pikslov na tipalu
0MP

Velikost pixla
12μm

NETD.
60<mk< td=””></mk<>

Osveževanje slike
50Hz

Kalibracija

Temperaturna občutljivost
0mK

Tip zaslona
LCOS

Ločljivost zaslona
960×720

Št. pikslov na zaslonu
0.69MP

Zajem slike
Ne

Ločljivost slike

Zajem videa
Ne

Ločljivost videa

Video izhod
Ne

Dolžina
143mm

Širina
41mm

Višina
69mm

Teža
230g

Material
Ne

Barva
Črna

Temperaturno območje
-10 ° / + 40° C

Tip baterije
Li-ion

Čas delovanja
4h

Polnilo
Dušik

Sistem ostrenja
Ne

Nastavitev dioptrije
Ne

Odpornost na vodo
IPX-7

Odpornost na rosenje
Da

Avtomatski izklop
Da

Navoj za stojalo
Ne

Kompas
Ne

Vgrajen daljinomer
Ne

Stabilizacija slike
Ne

Controla svetlosti
Ne
